CHROMA-L RGB Controller
0002-3-CON-L-20
- In stock, ready to ship
- Backordered, shipping soon
Managing longer runs of LED strips. The Chroma-Large controller supports up to 10 RF 2.4G remote controls and offers the same advanced functionalities—smooth, flicker-free dimming across 4096 levels and 10 dynamic RGB modes. It features an increased control distance and improved signal strength for reliable, seamless operation over extensive areas. The auto-transmitting function ensures easy synchronization across multiple controllers, while the selectable 3-second fade time provides gentle light transitions, making it ideal for expansive spaces needing consistent and comprehensive lighting control.
|
Input Voltage (VDC) |
12-48VDC |
|
Input Current (A) |
18.5A |
|
Output Voltage (VDC) |
3 X (12-48VDC) |
|
Output Current |
3CH, 6A/CH |
|
Output Power (W) |
3 X (72-288W) |
|
Output Type |
Constant Voltage |
|
Input Signal |
RF 2.4GHz + Push Dim |
|
Control Distance |
30m (Barrier Free Space) |
|
Dimming Gray Scale |
4096 (2^12) levels |
|
Dimming range |
0-100% |
|
Dimming Curve |
Logarithmic |
|
PWM Frequency |
1000Hz (default) |
|
Operation Temperature |
-20°C ~ +55°C |
|
Case Temperature (Max) |
+85°C |
|
IP Rating |
IP20 |
|
Warranty |
60 months from date of purchase |
|
Protection |
Reverse polarity |
|
Additonal Notes |
The output power of a constant voltage power supply should be at least 1.2 times that of the output load (light strip), otherwise the full power output of the load can easily cause automatic flickering or shaking of the light. |
Make life easier with all relevant downloadable information.
Explore our selection of compatible components to complete your setup seamlessly.
REMOTE CONTROLLERS
